LED
TD
HSDPA
Antennas, interface cables, and the connection methods
For more information about antennas, interface cables, and the connection methods for the
SIC-3G-GSM interface modules, see
Installing a SIM module
CAUTION:
Make sure the beveled corner of the SIM module fits into the beveled corner of the SIM socket.
To install a SIM module:
Open the SIM module socket in the direction marked OPEN so the holder projects upwards.
1.
Insert the SIM module into the SIM module socket along the guide rails.
2.
Close the SIM module socket in the direction marked LOCK to lock the card in position.
3.
Execute the display cellular [ interface-number ] command after the router is started. When
4.
"SIM Status = OK" appears in the output information, the SIM module is identified.

SIC-3G-HSPA

Introduction
The SIC-3G-HSPA module provides access to 3G networks. It supports:
•
GPRS
•
EDGE
•
UMTS
•
HSDPA
Interface specifications
Table 54 Interface specifications
Item
Connector type
Number of connectors
Interface standard
Description
•
Steady yellow: The service is valid.
•
Off: No service.
•
Steady yellow: The service is valid.
•
Off: No service.
"3G interface."
Description
TNC: For connecting an antenna and accessing WLANs.
RJ-45: For connecting to a third-party WLAN debugging and testing software
such as CAIT of Qualcomm.
2 TNC RF
1 RJ-45
TNC RF: Omni antenna, supporting GPRS/EDGE/UMTS/HSDPA.
RJ-45: RS-232
