H3C PSR450 Series User Manual

H3C PSR450 Power Module Series User Manual-6PW105
H3C PSR450系列电源手册-6PW105
Overview 功能简介
H3C PSR450 power module series include PSR450-12A, PSR450-12A1, PSR450-12AHD, and
PSR450-12D. The PSR450-12A, PSR450-12A1, and PSR450-12AHD power modules support AC and
high-voltage DC inputs, and the PSR450-12AHD supports 240V/336V high-voltage DC input. The
PSR450-12D supports DC input. They can provide a maximum output of 450 W. The PSR450-12A
provides power module-side intake and port-side exhaust airflows. The PSR450-12A1, PSR450-
12AHD, and PSR450-12D provides port-side intake and power module-side exhaust airflows.
PSR450系列电源包括PSR450-12A、PSR450-12A1、PSR450-12AHD和PSR450-12D这四款电源。
其中PSR450-12A、PSR450-12A1、PSR450-12AHD均支持交流和高压直流输入、直流输出的交流电
源模块，其中PSR450-12AHD支持240V/336V高压直流输入；PSR450-12D是直流输入、直流输出的直
流电源模块。在这四款电源模块中，PSR450-12A是电源侧进风，端口侧出风的吹风电源模块；
PSR450-12A1、PSR450-12AHD、PSR450-12D是端口侧进风，电源侧出风的抽风电源模块。
The power modules provide the following features:
PSR450系列电源模块特点：
Self-protection—The power modules provide output overvoltage, output current limiting, output short
circuit, overtemperature, and input undervoltage protections. See the following table for the protection
and auto-recovery features of the power modules.支持保护功能—支持输入过流保护、输出限流保护、输
入欠压保护、输出过压保护、输出短路保护、过温保护等功能
Redundancy—Two power modules can be connected in parallel to achieve 1+1 redundancy and load
sharing.支持冗余备份—支持双电源模块并联工作，以实现电源系统1+1备份，并且备份电源间具有负载
均流功能
Hot swapping—You can remove one of the two power modules in 1+1 redundancy while the device is
operating.支持热插拔—在设备正常工作的情况下，可对1+1冗余备份电源系统中的某个电源模块进行插拔
操作
Protection function Protection state
保护功能 保护状态特征
The power module does not
Output overvoltage
supply power, and the power
protection
module status LED is steady red.
输出过压保护
无输出，指示灯红灯常亮
The power module does not
Output current
supply power, and the power
limiting protection
module status LED is steady red.
输出限流保护
无输出，指示灯红灯常亮
The power module does not
Output short circuit
supply power, and the power
protection
module status LED is steady red.
输出短路保护
无输出，指示灯红灯常亮
BOM: 3101A0MY
Support for auto-recovery
恢复特性
No. Power supply can restore only
when you reconnect the power cord
to the power source.
故障排除后，重新插拔输入线缆电源
可恢复，指示灯绿灯常亮
Power supply restores after the output
current decreases to an acceptable
range.
故障排除后可自恢复，指示灯绿灯常亮
Power supply restores after the short
circuit problem is resolved.
故障排除后可自恢复，指示灯绿灯常亮
Protection function Protection state
保护功能 保护状态特征
The power module does not
Overtemperature
supply power, and the power
protection
module status LED is steady red.
过温保护
无输出，指示灯红灯常亮
The power module does not
Input undervoltage
supply power, and the power
protection
module status LED is flashing red.
输入欠压保护
无输出，指示灯红灯闪烁
Technical specifications 电源模块规格
Whether the power module supports high-voltage DC input depends on the device model. For
information, see hardware information and specifications for the device.
电源模块应用于不同设备上时，是否支持高压直流输入与设备型号有关，具体支持情况请参见设备配
套硬件描述。
Item 项目
Rated input voltage
额定输入电压范围
Rated input current
额定输入电流
AC input
交流输入
Max input voltage
最大输入电压范围
Max input current
最大输入电流
Rated input voltage
额定输入电压范围
Rated input current
额定输入电流
High-voltage
DC input
高压直流输入
Max input voltage
最大输入电压范围
Max input current
最大输入电流
Output voltage 输出电压
Output current 输出电流
Max output power 最大输出功率
Support for auto-recovery
恢复特性
Power supply restores after the output
current decreases to an acceptable
range.
故障排除后可自恢复，指示灯绿灯常亮
Power supply restores after the output
current decreases to an acceptable
range.
故障排除后可自恢复，指示灯绿灯常亮
Specifications 规格
PSR450-12A/PSR450-
PSR450-12AHD
12A1
100 to 240 VAC @ 100 to 240 VAC @
50 or 60 Hz 50 or 60 Hz
6 A 6 A
90 to 290 VAC @ 90 to 290 VAC @
47 to 63 Hz 47 to 63 Hz
7 A 7 A
240 VDC 240 to 380 VDC
3 A 3 A
180 to 320 VDC 180 to 400 VDC
3.5 A 3.5 A
12 V/3.3 V 12 V/3.3 V
37.5 A (12 V)/2 A (3.3 V) 37.5 A (12 V)/2 A (3.3 V)
450 W 450 W
