2: Installing the DCD in a Dual Head Octane2
80
15. Remove the nylon standoff that is located behind the daughterboard connector on
the VPro graphics board (see Figure 2-41), and store it with the DCD.
Figure 2-41 Removing the Nylon Standoff
Standoff
007-4209-003
