007-4209-003
5. Turn the Dual Head XIO Module over and remove the center plastic knob retaining
screw, as shown in Figure 2-34. Save the retaining screw for later in the installation.
Note: You may need to push in the knob slightly to be able to reach the screw with the
screwdriver.
Retaining screw
location
Figure 2-34 Removing the Center Plastic Knob Retaining Screw
6. Turn the Dual Head XIO Module back over, remove the center plastic knob, and
save it for later in the installation.
Removing the DCD
73
