1: Installing the DCD in a Single Head Octane2
VPro Graphics Board locator tabs
20
Note: After you complete step 8, make sure the locator tabs at each end of the VPro
graphics board I/O panel protrude through the locator slots on each end of the DCD
I/O panel, as shown in Figure 1-17.
VPro Locator Tabs Protrude through DCD Locator Slots
Figure 1-17
007-4209-003
