2: Installing the DCD in a Dual Head Octane2
76
9. Loosen (but do not remove) the four Phillips-head screws (items A, B, C, and D in
Figure 2-37) that hold the two plastic heat-sink stabilizer brackets.
A
B
Loosening the Heat-Sink Stabilizer Bracket Retaining Screws on the Graphics
Figure 2-37
Board I/O Panel
C
D
007-4209-003
