1: Installing the DCD in a Single Head Octane2

Removing the Cables from the XIO Tri-Module

6
1. Remove all the cables from the XIO Tri-Module (only the monitor cable on the VPro
graphics board is shown in Figure 1-3).
Note: The following illustrations show a workstation with a PCI module installed.
Your workstation may not have a PCI module, but the DCD installation is the same.
To monitor
Figure 1-3 Removing the Monitor Cable
007-4209-003
