5: Troubleshooting and Technical Specifications
Technical Specifications
Pin
Assignment
1
T.M.D.S. Data2-
2
T.M.D.S. Data2+
3
T.M.D.S. Data2/4 Shield
4
T.M.D.S. Data4-
5
T.M.D.S. Data4+
6
DDC Clock
7
DDC Data
8
Analog Vertical Sync
C1
Analog Red
C4
Analog Horizontal Sync
116
Table 5-2 lists the cable pinout assignments for both connectors on the DCD.
Table 5-2
DCD Pinout Assignment
Pin
9
10
11
12
13
14
15
16
C2
C5
Assignment
T.M.D.S. Data1-
T.M.D.S. Data1+
T.M.D.S. Data1/3 Shield
T.M.D.S. Data3-
T.M.D.S. Data3+
+5V Power
Ground
(return for +5V, HSync,
and VSync)
Hot Plug Detect
Analog Green
Analog Ground
(analog R, G, and B return)
Pin
Assignment
17
T.M.D.S. Data0-
18
T.M.D.S. Data0+
19
T.M.D.S. Data0/5 Shield
20
T.M.D.S. Data5-
21
T.M.D.S. Data5+
22
T.M.D.S. Clock Shield
23
T.M.D.S. Clock +
24
T.M.D.S. Clock-
C3
Analog Blue
