1: Installing the DCD in a Single Head Octane2
22
10. Place the screw you removed from the VPro graphics board into the hole behind the
DCD connector (above the standoff), then tighten the screw by turning it clockwise,
as shown in Figure 1-19.
The DCD is now securely connected to the VPro graphics board.
Standoff screw
Securing the DCD to the Standoff
Figure 1-19
