2: Installing the DCD in a Dual Head Octane2
84
21. Install the four nuts and lock washers on the BNC connectors, as shown in
Figure 2-45, but do not fully tighten them yet.
Note: These nuts are most easily installed using a socket wrench with a deep 9/16-inch
socket.
Figure 2-45
Installing the Nuts and Lock Washers on the Graphics Board I/O Panel
007-4209-003
