218 Fault tracing
Fault / Aux. code
Code
code visible only on
(hex)
assistant control panel
and drive composer)
D4B0 Running dry
D4B1 PV max volt
FF61 ID run
0005...0008 Internal error.
(aux
Cause
Dry run protection is activated.
The DC bus voltage in the
inverter is above the voltage
set in 79.43 PV cell max
voltage.
Motor ID run was not
completed successfully.
0001 Maximum current limit too low.
0002 Maximum speed limit or
calculated field weakening
point too low.
0003 Maximum torque limit too low.
0004 Current measurement
calibration did not finish within
reasonable time
0009 (Asynchronous motors only)
Acceleration did not finish
within reasonable time.
What to do
Check the pump inlet for sufficient
water level. Check dry run protection
settings in parameter group
protections.
• Check the number of PV cells
connected in series.
• Ensure that voltage is less
than the voltage set in 79.43 PV cell max
voltage.
Check the nominal motor values in
parameter group 99 Motor
Check that no external control system is
connected to the drive.
Cycle the power to the drive (and its
control unit, if powered separately).
Check that no operation limits prevent
the completion of the ID run. Restore
parameters to default settings and try
again.
Check that the motor shaft is not locked.
Check settings of parameters
Motor nominal current and
Maximum current. Make sure that
30.17 > 99.06.
Check that the drive is dimensioned
correctly according to the motor.
Check settings of parameters
• 30.11 Minimum speed
• 30.12 Maximum speed
• 99.07 Motor nominal voltage
• 99.08 Motor nominal frequency
• 99.09 Motor nominal
Make sure that
• 30.12 > (0.55 × 99.09) >
(0.50 × synchronous speed)
• 30.11 < 0, and
• supply voltage > (0.66 × 99.07).
Check settings of parameter
nominal torque, and the torque limits in
group 30 Limits.
Make sure that the maximum torque limit
in force is greater than 100%.
Contact your local ABB representative.
Contact your local ABB representative.
Contact your local ABB representative.
82 Pump
data.
99.06
30.17
speed.
99.12 Motor
