14 Introduction to the manual
Terms and abbreviations
Term/abbreviation
ACS-BP-S
ACS-AP-x
AI
AO
Control board
DC link
DC link capacitors
DI
DPMP-01
DPMP-02/03
Drive
EFB
FBA
FCAN-01
FECA-01
FENA-01/-11/-21
Frame (size)
IGBT
Intermediate circuit
Inverter
I/O
LSW
Macro
NETA-21
Network control
Explanation
Basic control panel, basic operator keypad for communication with the
drive.
Assistant control panel, advanced operator keypad for communication
with the drive.
The ACQ80 supports types ACS-AP-I, ACS-AP-S and ACS-AP-W.
Analog input; interface for analog input signals
Analog output; interface for analog output signals
Circuit board in which the control program runs.
DC circuit between rectifier and inverter
Energy storage which stabilizes the intermediate circuit DC voltage
Digital input; interface for digital input signals
Mounting platform for ACS-AP control panel (flange mounting)
Mounting platform for ACS-AP control panel (surface mounting)
Frequency converter for controlling AC motors
Embedded fieldbus
Fieldbus adapter
Optional CANopen adapter module
Optional EtherCAT adapter module
Optional Ethernet adapter module for EtherNet/IP, Modbus TCP and
PROFINET IO protocols
Refers to drive physical size, for example R0 and R1. The type
designation label attached to the drive shows the frame of the drive, see
chapter Operation principle and hardware description, section Type
designation label in the hardware manual of the drive.
Insulated gate bipolar transistor: used for high efficiency and fast
switching
See DC link.
Converts direct current and voltage to alternating current and voltage.
Input/Output
Least significant word
Pre-defined default values of parameters in drive control program. Each
macro is intended for a specific application. See chapter
on page 55.
Remote monitoring tool
With fieldbus protocols based on the Common Industrial Protocol
TM
(CIP ), such as Ethernet/IP, denotes the control of the drive using the
Net Ctrl and Net Ref objects of the ODVA AC/DC Drive Profile. For more
information, see www.odva.org, and the following manual:
FENA-01/-11/-21 Ethernet adapter module user's manual
(3AUA0000093568 [English]).
Control macros
