ABB DRIVES
UK gland plate (+H358)
ACS880-01, ACS580-01, ACH580-01,
ACQ580-01
Installation guide

Advertisement

Table of Contents
loading

Related Manuals for ABB ACS580-01

Summary of Contents for ABB ACS580-01

  • Page 1 — ABB DRIVES UK gland plate (+H358) ACS880-01, ACS580-01, ACH580-01, ACQ580-01 Installation guide...
  • Page 2 —...
  • Page 3 Installation guide UK gland plate (+H358) ACS880-01, ACS580-01, ACH580-01, ACQ580-01 Table of contents  2018 ABB Oy. All Rights Reserved. 3AXD50000034735 Rev B EFFECTIVE: 2018-11-21...

  • Page 5: Table Of Contents

    Table of contents 1 Table of contents Installation with option +H358 UK gland plate Safety instructions ............3 Introduction to the guide .
  • Page 6 2 Table of contents...

  • Page 7: Installation With Option +H358 Uk Gland Plate

    Applicability This guide is applicable to the following drives with option +H358 UK gland plate and degree of protection of IP21: • ACS880-01 • ACH580-01, ACQ580-01, ACS580-01. The guide is a supplement to the hardware manual.  Target audience This supplement is intended for people who plan the installation, install, start up, use and service the drive.

  • Page 8: Related Manuals

    3AXD50000044862 You can find manuals on the Internet. See www.abb.com/drives/documents. manuals not available in the document library, contact your local ABB representative. The code below opens an on-line listing of the manuals applicable to the product. ACH580-01 manuals ACS880-01 manuals...

  • Page 9: Frames R4 And R5: Removing The Power Clamp Shelf And Emc Shroud

    Installation with option +H358 UK gland plate 5 Frames R4 and R5: Removing the power clamp shelf and EMC shroud Remove the power cable clamp shelf and EMC shroud from the cable box for easier installation. Install the clamp shelf screws back to maintain the degree of protection. Go to section Making holes into the UK gland plate on page 7.

  • Page 10: Cable Box

    6 Installation with option +H358 UK gland plate Frames R6 to R9: Removing the standard bottom plate and power cable clamp shelf from the cable box Remove the bottom plate, side plates and the power cable clamp shelf as shown below.

  • Page 11: Making Holes Into The Uk Gland Plate

    Installation with option +H358 UK gland plate 7 Making holes into the UK gland plate Tools: Drill with step drill bits. 1. Take the UK gland plate from the drive package. R1 to R3 R4 to R5 R6 to R9...
  • Page 12 8 Installation with option +H358 UK gland plate 2. Prepare to make holes in the UK gland plate for the SWA glands of the cables to be installed. Lay out the glands onto the gland plate so that the earthing rings have space.

  • Page 13: Installing The Swa Glands

    Installation with option +H358 UK gland plate 9 Installing the SWA glands  SWA gland kit parts Contents of a SWA gland kit are shown below. Use appropriate kits for the cables to be connected. Lock nut Earthing ring Gland body Gland nut (locking part) Shroud ...

  • Page 14: Installing The Swa Gland Over A Power Cable

    10 Installation with option +H358 UK gland plate  Installing the SWA gland over a power cable See the drawings on the next pages. 1. Cut the shroud to fit the cable. Slide it over the cable. Measure the cable length that is required inside the drive.
  • Page 15 Installation with option +H358 UK gland plate 11...
  • Page 16 12 Installation with option +H358 UK gland plate...
  • Page 17 Installation with option +H358 UK gland plate 13...
  • Page 18 14 Installation with option +H358 UK gland plate...

  • Page 19: Installing The Swa Gland Over A Control Cable

    Installation with option +H358 UK gland plate 15  Installing the SWA gland over a control cable Peel off the sheath with electricians knife. Move the steel wires into two bundles. Twist the bundles to braids. Rotate the braids over the cone end of the gland body. Tighten the nut on the braids.

  • Page 20: Attaching The Uk Gland Plate To The Drive - Frames R1 To R5

    16 Installation with option +H358 UK gland plate Attaching the UK gland plate to the drive – Frames R1 to R5 Remove the rubber grommets. Attach the UK gland plate to the standard bottom plate from below with the nuts and screws included in the UK gland plate kit. R1, R2, R3...
  • Page 21 Installation with option +H358 UK gland plate 17 R4, R5...

  • Page 22: Attaching The Uk Gland Plate To The Drive - Frames R6 To R9

    18 Installation with option +H358 UK gland plate Attaching the UK gland plate to the drive – Frames R6 to R9 Attach the UK gland plate to the back plate of the cable box. Installing the drive on wall – Frames R1 to R4 See the hardware manual.

  • Page 23: Installing The Drive On Wall - Frames R5 To R9

    Installation with option +H358 UK gland plate 19 Installing the drive on wall – Frames R5 to R9 1. Mark the holes for the drive and the cable box onto the wall or where you intend to mount the drive. Place the fixings for the cable box and the drive ready for later.
  • Page 24 20 Installation with option +H358 UK gland plate 2. Install the cable box onto the wall.
  • Page 25 Installation with option +H358 UK gland plate 21 3. Install the drive above the cable box onto the fixings made earlier to take the weight of the drive. × 4...

  • Page 26: Connecting The Power Cables

    22 Installation with option +H358 UK gland plate Connecting the power cables 1. Connect the conductors to the terminals. See the drive hardware manual for the connection diagrams and tightening torques. Installation principle for frame R3 is shown below (similar for R1 and R2) and for R6 (similar for R7 to R9).
  • Page 27 Installation with option +H358 UK gland plate 23 2. For frame R4: Install the EMC shroud if removed. Install the shroud on the power cable terminals. 3. For frame R8: Install the shroud on the power cable terminals. Install side plates.
  • Page 28 24 Installation with option +H358 UK gland plate...
  • Page 29 Address any inquiries about the product to your local ABB representative, quoting the type designation and serial number of the unit in question. A listing of ABB sales, support and service contacts can be found by navigating to abb.com/searchchannels. Product training For information on ABB product training, navigate to new.abb.com/service/training.
  • Page 30 © Copyright 2018 ABB. All rights reserved. Specifications subject to change without notice.
