Chapter 1
Screen Operations
This chapter describes the ETERNUS Web GUI screen operations.
Click the [
explanation (help) screen of the function is displayed.
• Be sure to log out after all necessary operations are completed.
• If the operation screen is not updated when accessing ETERNUS Web GUI, close the web browser, and log
in again.
1.1

Overview

Overview screen appears immediately after logging in to ETERNUS Web GUI. The status of the ETERNUS DX/AF
storage systems and the usage of RAID groups, Thin Provisioning Pools (TPP), and Snap Data Pools (SDP) can
be checked in this screen.
• The [Initial Setup] screen is displayed for the first login after installation of the ETERNUS DX/AF is
complete.
• If the system message "Currently Network Configuration is set to factory default." is displayed, the net-
work environment settings for the MNT port must be performed. Use the [Setup Network Environment]
function in the [Network] screen under the [System] navigation. Some functions are not available if the
network environment settings are incomplete.
• If the system message "Configuration was applied to storage system." is displayed, the ETERNUS DX/AF
must be rebooted. Any setting processes cannot be performed until the applied configuration informa-
tion is enabled by rebooting the storage system.
• If the system message ""Expand Volume Mode" was updated. Please restart the storage system to update
"Expand Volume Mode" effectively." is displayed, the ETERNUS DX/AF must be rebooted. The number of
volumes and copy sessions is not increased until the ETERNUS DX/AF is rebooted and the new "Expand
Volume Mode" is specified.
• When the application schedule for controller firmware is being reserved, a message to that effect as well
as "Firmware Version", "Application Start Date", and "Apply Mode" are displayed. When the application
mode is "Update & Reboot", the ETERNUS DX/AF is automatically rebooted after the controller firmware is
applied.
• If the message which indicates that the controller firmware application has been reserved disappears
before the reserved date, the reservation may be canceled automatically. In this case, reserve the appli-
cation schedule for the controller firmware again. Refer to "Apply Controller Firmware" in "ETERNUS Web
GUI User's Guide (Settings)" for details.
] icon or the [Help] link for a detailed explanation of the functions used during operation. An
