  • Page 1 P3AM-8972-01ENZ0 FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview...
  • Page 2 This page is intentionally left blank.

  • Page 3: About This Manual

    Preface Fujitsu would like to thank you for purchasing our FUJITSU Storage ETERNUS DX60 S3 Disk storage system (hereinafter referred to as ETERNUS DX). The ETERNUS DX is designed to be connected to Fujitsu servers (Fujitsu M10, PRIMEQUEST, or PRIMERGY) or non-Fujitsu servers.

  • Page 4: Naming Conventions

    ® Microsoft Windows Server 2008 R2 for Itanium-Based Systems ® ® Microsoft Windows Server 2008 HPC Edition ® ® Microsoft Windows Server 2008 R2 HPC Edition FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...
  • Page 5 ■ Abbreviations Used in This Manual • "ETERNUS DX" refers to the FUJITSU Storage ETERNUS DX60 S3 Disk storage system. "CA" refers to a host interface module that is used in an ETERNUS DX to connect to a server. •...
  • Page 6 The black "Must Do..." circle indicates actions that must be taken. The required ac- tion is both illustrated inside the black disk and written above it (e.g. Unplug). FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED...
  • Page 7 - Be careful that no liquid seeps into the ETERNUS DX when using cleaners, etc. - Do not use alcohol or other solvents to clean the ETERNUS DX. Warning layout ribbon FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 8: Table Of Contents

    3.5 Environmental Burden Reduction....................34 3.5.1 Eco-mode................................34 3.5.2 Power Consumption Visualization........................35 3.6 Operation Management ....................... 35 3.6.1 Operation Management Interface........................35 3.6.2 Event Notification ...............................36 3.6.3 Performance Information Management......................37 FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...
  • Page 9 4.2.1 I/O Modules ................................58 4.2.2 Power Supply Units .............................58 4.2.3 Drives..................................58 4.3 Power Distribution Units (Only for Regions Other than EMEA&I)..........59 4.4 Power Synchronized Unit......................61 FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...
  • Page 10 Figure 4.10 Power Distribution Unit (AC200-240V, 1U, 4 Outlets)................59 Figure 4.11 Power Distribution Unit (AC200-240V, 2U, 12 Outlets)................60 Figure 4.12 Power Distribution Unit (AC200-240V, 2U, 16 Outlets)................61 FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...
  • Page 11 Power Distribution Unit (AC200-240V, 2U, 12 Outlets) and Provided AC Cable Specifications ....60 Table 4.11 Power Distribution Unit (AC200-240V, 2U, 16 Outlets) and Provided AC Cable Specifications ....61 FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 12: Chapter 1 Overview

    Host interfaces can be selected from FC 8Gbit/s, iSCSI 1Gbit/s, and SAS 6Gbit/s. Up to four ports can be instal- led in a single ETERNUS DX. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 13: High Reliability

    ● Model Upgrade As a support for system scalability after installation, an ETERNUS DX can be upgraded to a higher-end model. The ETERNUS DX60 S3 can be upgraded to the ETERNUS DX100 S3 . ■ High Reliability The high reliability of the ETERNUS DX enables operations to continue even when hardware fails. The ETER- NUS DX also protects data and provides high speed data access.
  • Page 14 Data can be replicated at any point with high speed by using the Advanced Copy functions in conjunction with software such as ETERNUS SF AdvancedCopy Manager. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...
  • Page 15 ■ Environmental Friendliness The ETERNUS DX is a green-certified product that satisfies Fujitsu's original strict environmental standards as part of its global efforts to reduce the environmental burden. The environmental burden is reduced by using a power saving design that allows reduced power consump- tion.

  • Page 16: Chapter 2 Specifications

    *2: The maximum physical capacity is calculated based on the assumption that 3.5" Nearline SAS disks are installed. The capacity is 24TB when 2.5" Nearline SAS disks are installed. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 17: Function Specifications

    *1: Use of RAID0 is not recommended because it is not redundant. For RAID0 configurations, data may be lost due to the failure of a drive. *2: Fujitsu original RAID level that provides the high speed rebuild function, and striping with double dis- tributed parity.

  • Page 18: Table 2.3 Supported Servers And Oss (Fc Interface)

    Fujitsu M10 Servers Solaris 11 RS/6000 AIX 5.3 P series AIX 6 System p AIX 7 Power Systems HP 9000 server HP-UX 11iV2 HP Integrity server HP-UX 11iV3 FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...
  • Page 19 SUSE Linux Enterprise Server 12 Oracle Linux 5 Oracle Linux 6 Oracle Linux 7 Oracle VM 3 VMware vSphere 5 VMware vSphere 5.1 VMware vSphere 5.5 XenServer 6 FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 20: Table 2.4 Supported Servers And Oss (Iscsi Interface)

    VMware vSphere 5.5 Oracle VM 3 XenServer 6 Oracle SPARC Enterprise Solaris 10 Fujitsu M10 Servers Solaris 11 HP 9000 server HP-UX 11iV3 HP Integrity server FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...
  • Page 21 SUSE Linux Enterprise Server 12 Oracle Linux 5 Oracle Linux 6 Oracle Linux 7 VMware vSphere 5 VMware vSphere 5.1 VMware vSphere 5.5 Oracle VM 3 XenServer 6 FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 22: Table 2.5 Supported Servers And Oss (Sas Interface)

    SUSE Linux Enterprise Server 11 SUSE Linux Enterprise Server 12 VMware vSphere 5 VMware vSphere 5.1 VMware vSphere 5.5 Oracle SPARC Enterprise Solaris 10 Fujitsu M10 Servers Solaris 11 FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...
  • Page 23 Red Hat Enterprise Linux 7 SUSE Linux Enterprise Server 10 SUSE Linux Enterprise Server 11 SUSE Linux Enterprise Server 12 VMware vSphere 5 VMware vSphere 5.1 VMware vSphere 5.5 FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 24: Eternus Web Gui/Eternus Cli Operating Environment

    Mozilla Firefox 3.6.x, ESR 10.0.x, ESR 17.0.x, ESR 24.0.x ● ETERNUS CLI When using ETERNUS CLI for operation management, prepare the telnet application, the SSH application, or the terminal emulator in the administration terminal. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 25: Chapter 3 Functions

    User data Controller CC: Check code Cache memory Written data The check codes are added The check codes are confirmed The check codes are confirmed and removed FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 26: Disk Drive Patrol

    Sign of Hot spare failure RAID5 (Redundant) Disconnects the maintenance target drive and switches it to the hot spare. RAID5 (Redundant) Disconnected FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 27: Rebuild/Copyback

    Replaces the failed drive with the new drive. Copyback After replacing has been completed, copies the data from the hot spare to the new drive. RAID5 (Redundant) Hot spare RAID5 (Redundant) FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 28: Fast Recovery

    The target drives for the Protection (Shield) function are all the drives that are registered in RAID groups or registered as hot spares. Note that the Protection (Shield) function is not available for unused drives. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED...

  • Page 29: Operations Optimization (Virtualization)

    Free area in the physical disk Vol.1 Vol.2 Vol.3 is shared with each volume. Free area Free area Used area Vol.1 to Vol.3 Used area FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 30: Optimization Of Volume Configurations

    Striping for Multiple RAID Groups Server I/O access performance can be improved by distributing the allocation of a volume across multiple RAID groups with Wide Striping. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 31: Security

    By setting which function can be used by each user, unnecessary access is reduced. ETERNUS DX AccountAdmin SecurityAdmin Maintainer User Account Storage System Security Management Management Management FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 32: User Authentication

    By defining a server that can access the volume, security can be ensured when multiple servers are connec- ted. A server can access the volume by associating the server that is allowed to access the volume with the vol- ume. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 33: Iscsi Security

    When bidirectional CHAP is used, the tar- get authenticates the initiator to prevent fraudulent access and the initiator authenticates the target to pre- vent impersonation. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 34: Environmental Burden Reduction

    SAS disks SAS disks SAS disks Backup Nearline SAS disks Nearline SAS disks Nearline SAS disks Disks stopped Disks spinning Disks stopped Control linked to operation FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 35: Power Consumption Visualization

    The settings that are required for the ETERNUS DX initial installation can be easily performed by following the wizard and inputting the parameters for the displayed setting items. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED...

  • Page 36: Event Notification

    The ETERNUS DX returns host senses (sense codes) to notify specific status to the server. Detailed informa- tion such as error contents can be obtained from the sense code. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED...

  • Page 37: Performance Information Management

    ETERNUS DX by graphically displaying the collected information on the GUI. An administra- tor can also use ETERNUS SF Storage Cruiser to monitor the performance threshold and specify how long per- formance information is retained. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 38: Device Time Synchronization

    The time is regularly corrected every three hours once the NTP is set. Figure 3.13 Device Time Synchronization NTP server Date and Time yyyy xx:xx:xx Time Zone + 09.00 Daylight Saving Time ETERNUS DX FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 39: Power Control

    For more details about power synchronized units, refer to "Configuration Guide (Power Synchronized Unit)". Figure 3.14 Power Synchronized Unit Diagram Server Server for server for server Power synchronized unit ETERNUS DX FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 40: Figure 3.15 Power Supply Control Using Wake On Lan

    The MAC address for the ETERNUS DX can be checked on ETERNUS Web GUI. Figure 3.15 Power Supply Control Using Wake On LAN Administration terminal Wake On LAN utility Packet transmission ETERNUS DX FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 41: Backup (Advanced Copy)

    There is one type of Advanced Copy: a local copy that is performed within a single ETERNUS DX. The following copy methods are available: • One Point Copy (OPC) QuickOPC • SnapOPC • SnapOPC+ • Equivalent Copy (EC) • FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 42: Stable Operation

    Figure 3.17 Host Response (Connection Operation Mode) Server A Server C Server B ETERNUS DX Host Response settings for Server A for Server B for Server C FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 43: Data Migration

    Web GUI. These functions enable integrated infrastructure management in a virtual environment. Note that some of these functions may require installation of plug-ins. Refer to the following site for more details: http://www.fujitsu.com/global/services/computing/storage/eternus/tools/ FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 44: Oracle Vm Linkage

    LUN creation, deletion, and expansion • Setting and deletion of the Management access groups (host affinity) server Oracle VM Manager ETERNUS DX Linkage software ETERNUS software (setup tool) FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 45: Vmware Linkage

    Storage DRS balances the loads on multiple physical servers in order to eliminate the need for performance management on each virtual machine. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED...
  • Page 46 VMware Web Client. Because storage side information is more visualized, integrated manage- ment of the infrastructure under a virtual environment can be realized and usability can be improved. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED...

  • Page 47: Microsoft Linkage

    Hyper-V • Space Reclamation Copy instruction ETERNUS DX Copying in a storage system SMI-S SCVMM management server SCVMM management console Linkage software ETERNUS software (setup tool) FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 48: Openstack Linkage

    This function can be used on UNIX OSs (includes Linux). LVM has a snapshot function. This function obtains any logical volume data as a snapshot and saves the snapshot as a different logical volume. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 49: Chapter 4 Hardware Configurations

    Two types of controller enclosures are available; a 2.5" type and a 3.5" type. ■ External Views of a 2.5" Type Controller Enclosure ● Front View Figure 4.1 Front View of a 2.5" Type Controller Enclosure 2.5" disk FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 50: Figure 4.2 Rear View Of A 2.5" Type Controller Enclosure (With One Controller Installed)

    Figure 4.3 Rear View of a 2.5" Type Controller Enclosure (with Two Controllers Installed) Controller (CM#0) Controller (CM#1) PWC port LAN (RMT) port LAN (MNT) port Host interface (CA#0) Power supply unit (PSU#0) Power supply unit (PSU#1) FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 51: Figure 4.4 Front View Of A 3.5" Type Controller Enclosure

    Controller (CM#0) Cover PWC port Drive interface (OUT) port LAN (RMT) port LAN (MNT) port Host interface (CA#0) Power supply unit (PSU#0) Power supply unit (PSU#1) FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 52: Controllers

    Multipath connection to a single server is not available. The Thin Provisioning function cannot be used. Fujitsu recommends that the dual-controller types, in which the controller and I/O module are duplica- • ted, be used in a system where a high level of reliability is required.

  • Page 53: Table 4.1 Host Interface Specifications

    The host interface specifications are shown below. Table 4.1 Host Interface Specifications Number of ports for each Interface Transfer rate (max.) Connector type controller 8Gbit/s iSCSI 1Gbit/s RJ-45 6Gbit/s miniSAS (SFF-8088) FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 54: Power Supply Units

    A controller enclosure has two power supply units. Each power supply unit contains fans. If one of the power supply units fails, the failed unit can be replaced while the system is running. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED...

  • Page 55: Drives

    The drive enclosure contains drives installed in the front, and I/O modules and power supply units in the rear. Drive enclosures can be added during system operation. When an error occurs, replacement operations can be performed while the system is running. FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 56: Figure 4.7 Front View Of A Drive Enclosure

    Figure 4.8 Rear View of a Drive Enclosure (Single-IOM Type) I/O module (IOM#0) Cover Drive interface (IN) port Power supply unit (PSU#0) Power supply unit (PSU#1) FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 57: Figure 4.9 Rear View Of A Drive Enclosure (Dual-Iom Type)

    Figure 4.9 Rear View of a Drive Enclosure (Dual-IOM Type) I/O module (IOM#0) I/O module (IOM#1) Drive interface (IN) port Power supply unit (PSU#0) Power supply unit (PSU#1) FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 58: I/O Modules

    Table 4.8 Drive Specification for 3.5" Drive Enclosures Product name Drive interface Storage capacity Rotational speed SAS disks Serial Attached SCSI 900GB, 1.2TB 10,000rpm Nearline SAS disks 2TB, 4TB, 6TB 7,200rpm FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 59: Power Distribution Units (Only For Regions Other Than Emea&I)

    Table 4.9 Power Distribution Unit (AC200-240V, 1U, 4 Outlets) and Provided AC Cable Specifications Item Specifications Power Voltage AC 200 – 240V Phase Single Frequency 50Hz/60Hz Input cable Connection type IEC60320 C13 n NEMA L6-15P Length Quantity FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 60: Figure 4.11 Power Distribution Unit (Ac200-240V, 2U, 12 Outlets)

    Table 4.10 Power Distribution Unit (AC200-240V, 2U, 12 Outlets) and Provided AC Cable Specifications Item Specifications Power Voltage AC 200 – 240V Phase Single Frequency 50Hz/60Hz Input cable Connection type Straight-through n NEMA L6-20P Length Quantity FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED P3AM-8972-01ENZ0...

  • Page 61: Power Synchronized Unit

    ETERNUS DX. For more details about power synchronized units, refer to "Configuration Guide (Power Synchronized Unit)". FUJITSU Storage ETERNUS DX60 S3 Disk storage system Overview Copyright 2014 FUJITSU LIMITED...
  • Page 62 However, Fujitsu shall assume no responsibility for any operational problems as the result of errors, omissions, or the use of information in this manual. Fujitsu assumes no liability for damages to third party copyrights or other rights arising from the use of any information •...
