Removal and Installation Procedures

Hard Disk Drive

4- - 34
1. Locate module to be removed: Locate the Hard Disk Drive in the locator
diagram Internal Modules, Figure 4- -8, page 4- -20.
CAUTION. Do not remove the replaceable hard disk drive when the mainframe is
powered on. Power down the instrument and then turn off the mains switch
located on the rear of the instrument (or remove the power cord).
Damage can occur to the replaceable hard disk drive and mainframe if the drive
is removed while the mainframe is powered on.
2. Orient the instrument: Set the instrument so its bottom is down on the work
surface and its rear panel is facing you.
3. Remove the hard disk drive: See Figure 4- -19, page 4- -35.
a. Verify that the chassis is powered down.
b. Remove the two thumbscrews from the front of the hard disk drive
assembly.
c. Grasp the hard disk drive assembly and slide it out of the instrument.
4. Reinstallation: Do step a. Then, in reverse, do steps b and c to reinstall the
hard disk drive assembly.
DSA8200 Digital Serial Analyzer and Modules Service Manual
