Maximum Configuration

Connect the Peripherals

DSA8200 Digital Serial Analyzer and Modules Service Manual
You can install up to two large sampling modules and four small modules for a
maximum of 12 inputs. Of these inputs, only eight inputs can be active at one
time. Also, note that installing a large module may disable a small-module
compartment. Refer to the DSA8200 Quick Start user manual for compartment
interaction.
Install probes, cables, and other connection accessories to your sampling
modules as appropriate for your application and sampling module. Again,
consult your sampling-module and connection-accessory manuals. Continue with
the next section after installing the sampling modules.
The peripheral connections are mostly the same as those you would make on a
personal computer. The connection points are shown in Figure 1- -2. See
Table 1- -1 on page 1- -3 for additional connection information.
NOTE. Before installing peripheral accessories to connectors (mouse, keyboard,
etc.), power down the instrument. See Powering Off the Instrument on page .

Table 1- 1: Additional accessory connection information

Item Description
Monitor If you use a non-standard monitor, you may need to change the the
Windows display settings to achieve the proper resolution for your monitor.
Printer Connect the printer to the EPP (enhanced parallel port) connector directly. If
your printer has a DB-25 connector, use the adapter cable that came with
your printer to connect to the EPP connector.
Rackmount Refer to the DSA8200, TDS8200, TDS8000, TDS8000B, CSA8200,
CSA8000, and CSA8000B Rackmount Installation Kit Instructions for
information on installing the rackmount kit.
Other Refer to the Application release notes (readme.txt) in the C:\Program
Files\DSA8200\System directory of the instrument for possible additional
accessory installation information not covered in this manual.
Installation
1- 3
