Removal and Installation Procedures
AC power cord
connector
Power
switch
AC power cord
Line fuse
holder
Line fuses
Figure 4- - 1: Line fuses and line cord removal
4- - 10
DSA8200 Digital Serial Analyzer and Modules Service Manual
