Replaceable Parts List
Figure 6- 9 Replaceable Parts List
Fig. & index Tektronix part
number number
6- - 9- - 1 174- - 4348- - 00
- - 2 174- - 4233- - 00
- - 3 174- - 4347- - 00
- - 4 174- - 4138- - 00
- - 5 174- - 4132- - 00
- - 6 174- - 4133- - 00
- - 7 174- - 4137- - 00
- - 8 174- - 4234- - 01
343- - 0459- - 00
6- 20
Serial number Serial number
effective discont'd
DSA8200 Digital Serial Analyzer and Modules Service Manual
Qty Name & description
2 CA ASSY, RF:COAXIAL,50 OHM,RG- - 316,12.00L,MCX RTANG PLUG 50
OHM TO MCX RTANG PLUG
4 CA ASSY,RF:COAXIAL,50 OHM, DSUB TO MCX- - B,R07CABL1
10 CA ASSY,RF:COAXIAL,50 OHM,RG- - 316,7.500L,X D- - SUB
3 CABLE ASSY,RF:COAXIAL,50 OHM,OPTICAL BD TO ACQ BD
1 CABLE ASSY,RF:COAXIAL,50 OHM,7.5 L,SMB TO PELTOLA
4 CABLE ASSY,RF:COAXIAL,50 OHM,14.0 L,MCX TO PELTOLA
2 CABLE ASSY,RF:COAXIAL,50 OHM,D- - SUB TO ACQ BD
1 CA ASSY,RF:COAXIAL,50 OHM, SMB TO MCX,R07CABL2
1 STRAP,TIEDOWN,E:0.098 W X 4.0 L,ZYTEL
(not shown on drawing)
