Tektronix DSA8200 Service Manual page 184

Replaceable Parts List
Figure 6- 10 Replaceable Parts List
Fig. & Index Tektronix part
number number
6- - 10- - 1 211- - 0088- - 00
- - 2 386- - 7293- - 00
- - 3 384- - 1838- - 00
- - 4 391- - 0239- - 00
- - 5 211- - 0088- - 00
- - 6 366- - 0804- - 00
366- - 0804- - 00
- - 7 211- - 0087- - 00
- - 8 214- - 4081- - 00
- - 9 380- - 1132- - 00
- - 10 333- - 4340- - 00
- - 11 335- - 0151- - 00
335- - 0152- - 00
335- - 0153- - 00
- - 12 380- - 1138- - 00
- - 13 333- - 4371- - 00
- - 14 335- - 0339- - 00
6- 22
Serial number Serial number
effective discont'd
DSA8200 Digital Serial Analyzer and Modules Service Manual
Qty Name & description
3 SCREW,MACHINE:2- - 56 X 0.281,FLH,82 DEG,STL BK OXD,POZ
1 PLATE,FRICTION
1 SHAFT; SCREW LOCKDOWN, 303 SST, R05HDSCR
1 LOCK SCREW:MOUNTING BLOCK
4 SCREW,MACHINE:2- - 56 X 0.281,FLH,82 DEG,STL BK OXD,POZ
1 KNOB:PUSH BUTTON, 0.11 OD, 0.33L, DELRIN, GRAY, 80E01
2 KNOB:PUSH BUTTON, 0.11 OD, 0.33L, DELRIN, GRAY, 80E02, 80E03,
80E04
2 SCREW,MACHINE:2- - 56 X 0.188,FLH,82 DEG SST,POZ
1 MTG,SCR LOCKDWN:ALUMINUM
1 HOUSING:SAMPLING HEAD,AL, 80E02
1 PANEL,FRONT:ALUMINUM,CHROMATE,W/TEK SILVERGRAY
1 MARKER,IDENT:LABEL,0.010 POLY,W/ADHESIVE,80E02
1 MARKER,IDENT:LABEL,,0.010 POLY,W/ADHESIVE,80E03
1 MARKER,IDENT:LABEL,0.010 POLY,W/ADHESIVE,80E04
1 HOUSING:ALUMINUM,SAMPLING HEAD 80E01
1 PANEL,FRONT:ALUMINUM,CHROMATE,W/TEK SILVERGRAY
1 MARKER,IDENT:LABEL,0.010 POLY,W/ADHESIVE, 80E01
