Figure 4- -8: Internal Modules - Tektronix DSA8200 Service Manual

Removal and Installation Procedures
Fan assembly
Display adapter
board
Display inverter
board
Standby/On switch
Display module
Figure 4- - 8: Internal modules
4- - 20
CD--RW/DVD/HD Interface board
(serial number B029999 and below)
Microprocessor
Fan and heat sink
CD drive
CD drive trim
Front panel
assembly
assembly
Front panel knobs
Front panel board
Front panel keypad
DSA8200 Digital Serial Analyzer and Modules Service Manual
Hard-drive
Drive frame
ATX chassis
ATX board
Bridge board
Processor board
Low-voltage power
supply assembly
Electrical frontend
board
Acquisition board
Rear power
distribution
board
Front power
distribution
board
