DSA8200 Digital Serial Analyzer and Modules Service Manual
3. Remove the cover: See Figure 4- -48, page 4- -78.
a. Remove the six Phillips screws that secure the cover to the chassis.
b. Slide the chassis out toward the rear of the cover.
4. Remove the lock-down shaft and bracket: See Figure 4- -48, page 4- -78.
a. Remove the two Phillips screws that secure the bracket to its mount.
Remove it.
b. Lift out the lock-down shaft.
5. Reinstallation: Perform steps 2 through 4 in reverse to reassemble the
module.
a. If installing a replacement the front panel, do the following steps before
performing step 2:
Remove the backing from the front panel label.
Align the holes and attach to the front panel.
b. If installing a replacement cover, do the following steps before perform-
ing step 3:
Remove the backing from the antistatic label.
Install the antistatic label to the replacement cover.
Removal and Installation Procedures
4- - 79
