After Repair

Installing the Instrument Model and Serial Number

DSA8200 Digital Serial Analyzer and Modules Service Manual
After removal and replacement of a module due to electrical failure, you must
perform the adjustment or software update as indicated in Table 4- -6.
Table 4- - 6: Action required for module replaced
Module replaced
Front panel assembly
Acquisition board
PPC processor board
ATX processor assembly
Display panel or display system
Power supply
Interconnect boards
Fans
If you have replaced the Power PC board in the instrument, you will need to
reload the instrument model and serial number. If you have installed an exchange
sampling head, you will need to reload the correct sampler serial number.
To install a model or serial number into the instrument do the following steps:
1. Connect a PC with a GPIB interface to the GPIB interface of the instrument.
CAUTION. Make sure the unique identifier does not end in all zeros before
generating or setting the key.
2. Enter the following GPIB commands, if necessary install a new instrument's
model number:
SYST:PROT OFF
SYST:PROP:MAI:MODE "DSA8200"
SYST:PROT ON
Adjustment required Software update required
No None
Yes Boot ROM and
authorization code
Yes Boot ROM and
authorization code
No
Windows, instrument
application
No None
Yes None
No None
No None
Troubleshooting
4- - 89
