Removal and Installation Procedures

Procedures for Modules

4- - 22
You should have completed the Procedures for external modules before doing
many of the procedures in this collection. The procedures found here are listed in
disassembly order:
Front Panel Assembly
Front Panel Board
Front Panel Keypad
Display Assembly
Display Adapter Board
Standby/On Switch Flex Circuit
Hard Disk Drive
CD-RW/DVD Drive
CD-RW/DVD and Hard Disk Drive Mounting Frame
ATX Board Assembly
ATX Board
Microprocessor
Front and Rear Power Distribution Boards
PC Processor Board
Low-Voltage Power Supply
Fan Assembly
Acquisition Assembly
Large Module Interface Board
Module Slot Doors
Electrical Modules
Optical Modules
80A00 and 82A00 Series Modules
DSA8200 Digital Serial Analyzer and Modules Service Manual
