Tektronix DSA8200 Service Manual page 186

Replaceable Parts List
Figure 6- 11 Replaceable Parts List
Fig. & index Tektronix part
number number
6- - 11- - 1 200- - 4568- - 00
- - 2 335- - 0370- - 00
- - 3 211- - 0373- - 00
- - 4 105- - 1115- - 00
- - 5 011- - 0176- - 00
2
1
3
4
5
Figure 6- 11: 80E05 module (Option 10G shown)
6- 24
Serial number Serial number
effective discont'd
4
DSA8200 Digital Serial Analyzer and Modules Service Manual
Qty Name & description
1 COVER:OPTICAL MODULE,0.050 AL
1 MARKER,IDENT:ANTI- - STATIC LABEL,0.005 POLY
12 SCREW,MACHINE:4- - 40 X 0.250,PNH,STL CD PLT,T10
13 SCREW,MACHINE:4- - 40 X 0.250,PNH,STL CD PLT,T10 (OPTION 10G)
2 LATCH:ADJUSTABLE GRIP,16- - 10- - 511- - 16
5 TERM,RF; SMA,PLUG,STR,SST,W/BEAD CHAIN
6 TERM,RF; SMA,PLUG,STR,SST,W/BEAD CHAIN
(OPTION 10G)
3
