Required Equipment; Instrumentation Setup; Table 3- 2: Required Equipment And Materials - Tektronix DSA8200 Service Manual

Adjustment Procedures

Required Equipment

Instrumentation Setup

3- 2
The adjustment procedure requires the specific test equipment and materials
listed in Table 3- -2.

Table 3- 2: Required equipment and materials

Category Specific equipment required
Signal source Signal generator 50 MHz to 1 GHz, ≤1 ppm
frequency accuracy
Meter Digital Multimeter, with 6.5 plus digits
Instrument controller PC-compatible computer with National Instruments
(only one of these GPIB Controller card and software, running Windows
configurations 95/98 or NT
required) required)
National Instruments USB GPIB Controller card for
Windows 98 and National Instruments NI-488.2 for
Windows software (to install in the instrument)
Divider Power, 50 Ω, SMA "T". male Tektronix 015-0565-00
Adapter SMA "T", male to 2 SMA female Tektronix part
number 015-1016-00
Adapter SMA male to BNC female, Tektronix part number
015-0554-00
Adapter BNC to dual banana plug, Tektronix part number
103-0095-00
Coaxial cables 50 Ω, male-to-male SMA connectors
GPIB cables GPIB cable, 1 m minimum length, Tektronix part
number 002-0991-01
1
Depending on other USB devices attached to the instrument, a USB hub may also
be required. Consult your National Instruments documentation for more
information.
Set the National Instruments GPIB Interface command software to allow GPIB
communications between the PC controller and DSA8200, device under test
(DUT).
Before you can execute the adjustment program, you need to set up and
configure the instrumentation. Make connections according to the following
diagrams. See Figure 3- -1.
To perform this procedure you must have the specific equipment listed in
Table 3- -2.
DSA8200 Digital Serial Analyzer and Modules Service Manual
Quantity
1 ea
1 ea
1 ea
1 ea
1
1 ea
1 ea
1 ea
1 ea
3 ea
1 ea
