Replaceable Parts List
Figure 6- 17 Replaceable Parts List
Fig. & index Tektronix part
number number
6- - 17- - 1 211- - 0088- - 00
- - 2 386- - 7293- - 00
- - 3 384- - 1838- - 00
- - 4 391- - 0239- - 00
- - 5 335- - 0370- - 00
- - 6 211- - 0087- - 00
- - 7 380- - 1159- - 00
- - 8 333- - 3451- - 00
- - 9 335- - 1317- - 00
- - 10 344- - 0623- - 00
- - 11 011- - 0176- - 00
6- 30
Serial number Serial number
effective discont'd
DSA8200 Digital Serial Analyzer and Modules Service Manual
Qty Name & description
6 SCREW,MACHINE:2- - 56 X 0.281,FLH,82 DEG,STL BK OXD,POZ
1 PLATE,FRICTION
1 SHAFT; SCREW LOCKDOWN, 303 SST, R05HDSCR
1 LOCK SCREW:MOUNTING BLOCK
1 MARKER,IDENT:ANTI- - STATIC LABEL,0.005 POLY
2 SCREW,MACHINE:2- - 56 X 0.188,FLH,82 DEG SST,POZ
1 HOUSING:SAMPLING HEAD,ALUMINUM, SAFETY CONTROLLED
1 PANEL,FRONT:PATTERN TRIGGER
1 MARKER,IDENT:LABEL,MKD 80A06 PATTERN TRIGGER MODULE,2.760
X .810,LEXAN,
3 CLIP, SMA CONNECTOR FOR TERMINATION W/CHAIN, POLYPROPY-
LENE, SILVER GRAY
3 TERM,RF; SMA,PLUG,STR,SST,W/BEAD CHAIN
