Removal and Installation Procedures

Preparation

DSA8200 Digital Serial Analyzer and Modules Service Manual
This subsection contains procedures for removal and installation of all mechani-
cal and electrical modules.
WARNING. Before doing this or any other procedure in this manual, read the
Safety Summary found at the beginning of this manual. Also, to prevent possible
injury to service personnel or damage to this instrument's components, read
Installation in Chapter 2, and Preventing ESD in this section.
This subsection contains the following items:
Preparatory information that you need to properly do the procedures that
follow.
A list of tools required to remove and disassemble all modules.
Procedures for removal and reinstallation of the electrical and mechanical
modules.
A disassembly procedure for removal of all the major modules from the
instrument at one time and for reassembly of those modules into the
instrument. Instructions for doing the actual cleaning are found under
Inspection and Cleaning at the beginning of this section.
Module disassembly procedures.
WARNING. Before doing any procedure in this subsection, disconnect the power
cord from the line voltage source. Failure to do so could cause serious injury or
death.
NOTE. Read Equipment Required for a list of the tools needed to remove and
install modules in this instrument. See Table 4- - 3, page 4- - 8.
Read the cleaning procedure before disassembling the instrument for cleaning.
4- - 7
