Removal and Installation Procedures
4- - 38
b. Pull the drive straight toward you until the drive detaches from the
CD/HD interface board.
5. Reinstallation: Do in reverse steps 3 and 4 to reinstall the CD-RW/DVD
drive.
CD--RW/DVD
drive assembly
CD--RW/DVD drive trim
Phillips screw (2)
Figure 4- - 22: CD- - RW/DVD disk drive removal (serial number B029999 and below)
DSA8200 Digital Serial Analyzer and Modules Service Manual
