Electrical Sampling Modules Block Diagram
Channel 1
Six-diode traveling wave
sampler (80E01, 80E02,
80E03, 80E04, 80E06)
User Input
Two-diode low noise
sampler (80E07,
80E08, 80E09,
TDR Step Generator
(80E04 , 80E08, 80E10
Channel 2
(all except the 80E01 & 80E06)
Six-diode traveling wave
sampler (80E01, 80E02,
80E03, 80E04, 80E06)
User Input
Two-diode low noise
sampler (80E07,
80E08, 80E09,
TDR Step Generator
(80E04 , 80E08, 80E10
Figure 5- 2: Block diagram for the 80E00 Series Electrical Sampling Modules
DSA8200 Digital Serial Analyzer and Modules Service Manual
Figure 5- -2 shows the interconnections between major circuit blocks of all
electrical sampling modules.
I/O
80E10)
only)
I/O
80E10)
only)
