Tektronix DSA8200 Service Manual page 174

Replaceable Parts List
Figure 6- 5 Replaceable Parts List
Fig. & index Tektronix part
number number
6- - 5- - 1 441- - 2558- - 00
- - 2 343- - 0549- - 00
- - 3 214- - 3903- - 00
- - 4 174- - 4807- - 00
- - 5 174- - 4808- - 00
- - 6 671- - 6279- - 01
- - 7 146- - 0096- - 00
- - 8 174- - 4798- - 00
- - 9 119- - 7220- - 00
- - 10 174- - 4797- - 00
- - 11 167- - 1048- - 00
- - 12 211- - 1050- - 00
- - 13 131- - 6417- - 00
- - 14 343- - 1683- - 00
6- 12
Serial number Serial number
effective discont'd
DSA8200 Digital Serial Analyzer and Modules Service Manual
Qty Name & description
1 CHASSIS, ASSEMBLY (ATX) (FINISHED),SAFETY CONTROLLED
1 STRAP,TIEDOWN; 0.098 W X 4.0 L,ZYTEL
6 SCREW, JACK; 4- - 40 X 0.312 LONG, 0.188 H HEX HEAD STAND OFF,
4- - 40 INT THD, X 0.312 THD EXT 4- - 40, STEEL, SN PLATED
1 CA ASSY; ATX USB, PLUS MISC. TO DISPLAY,SAFETY CONTROLLED
1 CABLE ASSY,RF; 75 OHM COAX,5.5 L,SEMI RIGID
1 CKT BD SUBASSY; TESTED PROCESSOR,FOR HPP:DSA8200; SAFETY
CONTROLLED
1 BATTERY,DRY; 3.0V,LITHIUM MANGANESE DIOXIDE,210MAH,20 X
3.2MM COINCELL,CR2032,SAFETY CONTROLLED
1 CA ASSY; 4 PIN P4 POWER,SAFETY CONTROLLED
1 PROCESSOR; CELERON D,2.93 GHZ,64BIT,1.287V TO 1.4V
CORE,84W,BUS SPD 533MHZ,FC- - LGA4 775 PKG,W/12V FAN&HEAT-
SINK,BX80547RE2933CN,INTEL
1 CA ASSY; 20 PIN ATX POWER,SAFETY CONTROLLED
1 IC,MEMORY;128M X 64,1GB DDR2 1.8V,3- - 3- - 3,667 MHZ;
MT8HTF12864AY- - 667E1,DIMM240,DS1
8 SCREW,MACHINE:6- - 32 X 0.312 L,PNH,STL CAD,T15
2 CONTACT,ELEC; GROUNDING,0.600 L X 0.250 W X 0.220 D,ELECTRO-
LESS NICKEL PLATE
1 CLAMP, VERTICAL WIRE SADDLE, NYLON 6/6, SNAPS INTO .185 DIA
HOLE, 0.74 MAX CABLE DIAMETER
