CD-RW/DVD and Hard
Disk Drive Mounting
Frame (Serial number
B030000 and above)
DSA8200 Digital Serial Analyzer and Modules Service Manual
1. Locate module to be removed: Locate the CD-RW/DVD and hard drive
mounting frame in the locator diagram Internal Modules, Figure 4- -8, page
4- -20. Additional modules to be removed:
Trim (all)
Bottom cover
Left and Right covers
CD-RW/DVD drive
Hard drive
2. Orient the instrument: Set the instrument so its bottom is down on the work
surface and the side with the mounting drive side is facing you.
3. Remove the mounting frame. See Figure 4- -27, page 4- -44.
a. Remove the six T-15 Torxdrive screws that secure the mounting frame to
the ATX chassis.
b. Remove the CDD/HDD drive cable from the hard drive.
c. Remove the CD- -RW/DVD drive cable from the CD- -RW/DVD drive.
d. Grasp both far side corners of the drive frame.
e. Lift up and toward the rear of the instrument simultaneously.
f. Gently shift the frame from side to side as you pull it to the rear until you
can remove it completely.
4. Reinstallation: Do in reverse the substeps of step 3 to reinstall the CD-RW/
DVD and hard drive mounting frame.
Removal and Installation Procedures
4- - 43
