Tektronix DSA8200 Service Manual page 190

Replaceable Parts List
Figure 6- 15 Replaceable Parts List
Fig. & Index Tektronix part
number number
6- - 15- - 1 384- - 1838- - 00
- - 2 214- - 4081- - 00
- - 3 211- - 3008- - 00
- - 4 015- - 1022- - 01
- - 5 335- - 0370- - 00
- - 6 211- - 0088- - 00
- - 7 380- - 1151- - 00
- - 8 211- - 0087- - 00
- - 9 333- - 4392- - 00
- - 10 335- - 0485- - 00
9
10
Figure 6- 15: 80A01 module
6- 28
Serial number Serial number
effective discont'd
5
6
7
8
DSA8200 Digital Serial Analyzer and Modules Service Manual
Qty Name & description
1 SHAFT:SCREW LOCKDOWN,303 SST,R05HDSCR
1 LOCKDOWN:SCREW MOUNT,0.080 AL
2 SCREW,MACHINE:2- - 56 X 0.281,PNH,SST,PASS,POZI DR
1 TERMINATOR:COAXIAL, 50 OHM, 0.5W, SMA
1 MARKER,IDENT:ANTI- - STATIC LABEL,0.005 POLY
8 SCREW,MACHINE:2- - 56 X 0.281,FLH,82 DEG,STL BK OXD,POZ
1 HOUSING:SAMPLING MODULE,TRIGGER PRESCALE LIMITING PREAMP
2 SCREW,MACHINE:2- - 56 X 0.188,FLH,82 DEG SST,POZ
1 PANEL,FRONT:TRIGGER PRESCALE LIMITING PREAMP,AL ALLOY
1 MARKER,IDENT:LABEL,MKD 80A01 PRESCALE MODULE,2.760 X
.810,LEXAN,
2
4
3
1
