ATX Board (Serial Number
B029999 and Below)
DSA8200 Digital Serial Analyzer and Modules Service Manual
1. Locate module to be removed: Locate the ATX Board in the locator diagram
Internal Modules, Figure 4- -8, page 4- -20. Additional modules to be
removed:
Trim (all)
Bottom cover
Left and Right covers
CD-RW/DVD and Hard Drive mounting frame
ATX Board Assembly
2. Remove the ATX Board: See Figure 4- -30, page 4- -50.
3. Orient the ATX Assembly: Set the ATX Assembly so that the fan assembly is
up.
4. Remove the Riser Adapter and ATX boards:
a. Disconnect the J410 cable, the J3A4 cable and the blue CDD/HDD drive
cable from the ATX board.
b. Remove the eight T-15 Torxdrive screws that secure the ATX board to
the ATX chassis.
c. Remove the six 3/16 nut posts that secure the three connectors to the rear
of the support bracket.
d. Remove the ATX board from the support bracket.
5. Reinstallation: Do in reverse steps 4a and 4d to reinstall the ATX board.
Removal and Installation Procedures
4- - 49
