Accessories Replaceable Parts List (cont.)
Tektronix Serial number
part number effective
- - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - - - - -
- - - - - - - - - - - - - - - - - -
015- - 1022- - 00
015- - 1022- - 00
015- - 0703- - xx
650- - 4986- - xx
071- - 0434- - XX
012- - 1568- - 00
012- - 1569- - 00
015- - 1001- - 00
015- - 1002- - 01
071- - 0435- - XX
119- - 4514- - 00
119- - 4515- - 00
119- - 4516- - 00
119- - 4517- - 00
119- - 4518- - 00
119- - 4546- - 00
119- - 4556- - 00
119- - 4557- - 00
119- - 4558- - 00
119- - 4513- - 00
DSA8200 Digital Serial Analyzer and Modules Service Manual
Serial number
discont'd
Qty Name & description
DUAL DELAY LINE: DL- - 11
PROBE: P6209, 4.0 GHz ACTIVE FET PROBE
80A02 EOS/ESD PROTECTION MODULE:ELECTRICAL STATIC ISOLATION OF TEKTRONIX
ELECTRICAL SAMPLING MODULES
80E0X STANDARD ACCESSORIES
1 TERMINATOR, COA:SHORT CIRCUIT, SMA MALE
(80E01)
2 TERMINATOR, COA:SHORT CIRCUIT, SMA MALE
(80E02, 80E03 AND 80E04)
1 ADPTR,RF,PRCN:2.4MM OR 1.85MM MALE TO 2.92MM FEMALE (80E01 AND 80E06 ONLY)
1 ASSEMBLY,GUIDE RAILS W/HARDWARE
(80E07, 80E08, 80E09, AND 80E10 ONLY)
80E0X OPTIONAL ACCESSORIES
1 MANUAL,TECH:SAMPLING MODULE USER
1 CA ASSY:SSP,ELEC,1 METER LONG, EXTENDER
1 CA ASSY:SSP,ELEC,2 METER LONG, EXTENDER
1 ATTENUATOR, FIX:2:1 ATTENUATION, 50 OHM, SERIES SMA CONNECTORS
1 ATTENUATOR, FIX:5:1 ATTENUATION, 50 OHM, SERIES SMA CONNECTORS
80C0X OPTIONAL ACCESSORIES
1 MANUAL,TECH:OPTICAL MODULE USER
1 ADAPTER,D4:TFS3030,AD4- - 20
1 ADAPTER,BICONIC:TFS3030,AB1- - 25
1 CONNECTOR, OPTO:ADAPTER, FC- - PC, ATTEN 0.6DB, RTN LOSS 35DB, RPTB+/- - 0.2DB,
RIFOCS, APC- - 10
1 ADAPTER,SMA:TFS3030,2.5MM,AMT- - 10
1 ADAPTER,SC:TFS3030,ASC- - 10
1 ADAPTER,DIN:47256,AD- - 234
1 ADAPTER,HP- - PC:OPTICAL CONNECTOR, UNIVERSAL CONNECTOR INTERFACE, AHP- - 10
1 ADAPTER,UNIV:SMA 905/906,ASM- - 90
1 ADAPTER,UNIV:DIAMOND 3.5MM,AMS- - 00
1 CONNECTOR, OPTO:ADAPTER, ST, ATTEN 0.6DB, RTN LOSS 35DB, RPTB
+/- - 0.2DBRIFOCS, ATS- - 16
Replaceable Parts List
6- 33
