Replaceable Parts List
Figure 6- 7 Replaceable Parts List
Fig. & index Tektronix part
number number
6- - 7- - 1 441- - 2479- - 00
441- - 2479- - 01
- - 2 119- - 6697- - 03
- - 3 211- - 1050- - 00
- - 4 131- - 1315- - 01
- - 5 103- - 0269- - 00
- - 6 131- - 0850- - 00
- - 7 210- - 0457- - 00
- - 8 210- - 0465- - 00
- - 9 650- - 4086- - 00
- - 10 210- - 1443- - 00
- - 11 136- - 0140- - 00
6- 16
Serial number Serial number
effective discont'd
B010100 B010272
B010273
DSA8200 Digital Serial Analyzer and Modules Service Manual
Qty Name & description
1 CHASSIS ASSEMBLY (MAIN), SAFETY CONTROLLED
1 CHASSIS ASSEMBLY (MAIN), SAFETY CONTROLLED
1 POWER SUPPLY; CUSTOM,AC- - DC;375W,85- - 275VAC
45- - 66HZ,95- - 132VAC 360- - 440 HZ IN,+3.3V 35A +5V 22A +5.0VSB 1A;+12V
6A +VFAN 2.5A +5V 18A - - 5.2V 12A +15V 3A - - 15V 3A OUT;CONTROL
SIGNALS:POWERFAIL,ON/STDBY,LINE TRIG;SAFETY CONTROLLED
8 SCREW,MACHINE:6- - 32 X 0.312 L,PNH,STL CAD PLT,T15
1 CONN,RF JACK:BNC/PNL,50 OHM,FEMALE,STR,PELTOLA
3 ADAPTER,CONN:SMA TO PELTOLA,FEMALE TO FEMALE,STR,PNL,D/
FLAT,0.385 MTG HOLE,GOLD/NICKEL
1 CONN,JACK,RF:SMA,FEEDTHRU,DUAL FEMALE,STR,50 OHM,0.25 MTG
W/ 0.375HEX,0.59 X 0.24 MLG,GOLD/SS
1 NUT,PL,ASSEM WA:6- - 32 X 0.312,STL CD PL,W/LOCKWASHER
1 NUT,PLAIN,HEX:0.25- - 32 X 0.375,BRS CD PL
1 CABLE ASSEMBLY:ELECT,ANTI STATIC CONNECTION
1 WASHER,FLAT:0.25 ID X 0.375 OD X 0.265,NYLON
1 JACK,TIP:BANANA,CHARCOAL GRAY
