80C10 Optical Sampling
Module
80C10B Optical Sampling
Module
80C11 Optical Sampling
Module
DSA8200 Digital Serial Analyzer and Modules Service Manual
Clock recovery options are available (OC-192 and FEC10.709)
The 80C10 module is designed to test long wavelength (1310 and 1550 nm)
signals. This module is intended to be used as a test and measurement tool for
high bandwidth telecommunications with its high optical bandwidth >65 GHz.
Supported standards or data filtering rates include OC-768 and FEC43.02
(G.709).
30 GHz: The sampler bandwidth and response is set during the calibration
such that the combined system will have an Optical Bandwidth (- -6 dB)
>30 GHz.
65 GHz: The sampler bandwidth and response is set during the calibration
such that the combined system will have an Optical Bandwidth (- -6 dB)
>65 GHz.
There is no clock recovery option available.
The 80C10B module is designed to test long wavelength (1310 and 1550 nm)
signals. This module is intended to be used as a test and measurement tool for
high bandwidth telecommunications with its high optical bandwidth >80 GHz.
Supported standards or data filtering rates include OC-768, 40GBase- -FR,
and FEC43.02 (G.709). Option F1 adds support for 100GBase- -LR4+FEC,
100GBase- -ER4+FEC, and 25.781 Gb/s (100GBase- -LR4 and 100GBase- -
ER4).
30 GHz: The sampler bandwidth and response is set during the calibration
such that the combined system will have an Optical Bandwidth (- -6 dB)
>30 GHz.
65 GHz: The sampler bandwidth and response is set during the calibration
such that the combined system will have an Optical Bandwidth (- -6 dB)
>65 GHz.
80 GHz: The sampler bandwidth and response is set during the calibration
such that the combined system will have an Optical Bandwidth (- -6 dB)
>80 GHz. Not available with Option F1.
Option CRTP provides electrical signal outputs for use with the Tektronix
CR286A Option HS clock recovery device, or other compatible clock
recovery devices.
The 80C11 module is designed to test long wavelength (1100- -1650 nm) signals.
This module is intended to be used as a test and measurement tool for high
bandwidth telecommunications with its high optical bandwidth >20 GHz.
Theory of Operation
2- 11
