Diagrams
Optical Sampling Modules Block Diagrams
80A01 Block Diagram
Power
LED
Input
Output
Figure 5- 3: 80A01 block diagram
5- 4
Contact Tektronix Customer Support to request information about the internal
signal flow for optical sampling modules.
Figure 5- -3 show the interconnections between major circuit blocks of the 80A01
module.
RF Amplifier
DSA8200 Digital Serial Analyzer and Modules Service Manual
LED Driver
Curtain
Board
