DSA8200 Digital Serial Analyzer and Modules Service Manual
5. Remove the module slot doors: See Figures 4- -42 and 4- -43, pages 4- -70
and 4- -71.
6. Orient the small or large module chassis: Set the chassis so the module slot
cavities with springs and slot guides are facing you.
a. Remove both slot door springs by prying the spring arm from the small
slots located on the sides of the module slot. Use a pair of tweezers to
pull the spring arms out from the slot.
NOTE. There is a right and left spring, note locations of the springs for later
reassembly.
b. Push the module slot door slighting in while lifting the door out of the
chassis.
Removal and Installation Procedures
4- - 69
