Removal and Installation Procedures
4- - 52
.
Securing nuts (6)
To ATX12V
To J510 on
Processor board
To J410 on
Processor board
Figure 4- - 31: ATX board removal (serial number B030000 and above)
DSA8200 Digital Serial Analyzer and Modules Service Manual
To J1 on USB
assembly
To J182 on
Processor board
To USB56
To F PANEL
ATX12V
USB56
SATA1 -- 4
F PANEL
Hard drive and
CD/DVD drive
To J300 on
Processor board
T--15 Torx
screw (8)
EATXPWR1
To EATXPWR1
