Tektronix DSA8200 Service Manual page 180

Replaceable Parts List
Figure 6- 8 Replaceable Parts List
Fig. & index Tektronix part
number number
6- - 8- - 1 441- - 2176- - 00
- - 2 211- - 1050- - 00
- - 3 671- - 4483- - 00
- - 4 174- - 4046- - 00
- - 5 351- - 1068- - 00
- - 6 129- - 1516- - 00
- - 7 210- - 0457- - 00
- - 8 174- - 4045- - 01
- - 9 Order 4- - 11
- - 10 Order 4- - 11
- - 11 650- - 4608- - 00
- - 12 351- - 1067- - 00
- - 13 174- - 4043- - 00
- - 14 211- - 0815- - 00
- - 15 174- - 4902- - 00
- - 16 441- - 2175- - 01
- - 17 211- - 0373- - 00
- - 18 355- - 0259- - 00
- - 19 214- - 4893- - 00
- - 20 200- - 4560- - 00
- - 21 214- - 4892- - 00
- - 22 105- - 1132- - 00
- - 23 210- - 0185- - 00
- - 24 366- - 0815- - 00
- - 25 105- - 1131- - 00
- - 26 214- - 4891- - 00
- - 27 355- - 0297- - 00
- - 28 200- - 4561- - 00
- - 29 200- - 4876- - 00
- - 30 211- - 0967- - 00
- - 31 129- - 0208- - 00
6- 18
Serial number Serial number
effective discont'd
DSA8200 Digital Serial Analyzer and Modules Service Manual
Qty Name & description
1 CHASSIS ASSY:LARGE MODULE,0.050 AL
21 SCREW,MACHINE:6- - 32 X 0.312 L,PNH,STL CAD PLT,T15
1 CIRCUIT BD ASSY:OPTICAL FRONT END
1 CA ASSY,SP:RIBBON,BUS PROCESSOR,IDC,32 AWG
4 GUIDE:CARD GUIDE
3 SPACER, POST:ECB- - 1.077,0.250 HEX 12L 14 STEEL
20 NUT,PL,ASSEM WA:6- - 32 X 0.312,STL CD PL,W/LOCKWASHER
2 CA ASSY,SP:RIBBON,BUS ACQUISITION,IDC,32 AWG
1 CIRCUIT BD ASSY:SMALL MODULE INTERFACE
Part of item 4- - 11: COMBO ASSEMBLY:ACQP/EFE
1 CKT BD SUBASSY:ACQ BOARD
Part of item 4- - 11: COMBO ASSEMBLY:ACQP/EFE
1 COMBO ASSEMBLY:ACQP/EFE
8 GUIDE:CARD GUIDE,E- - 300
1 CA ASSY,SP,ELEC:DISCRETE,TRIGGER PROBE POWER
3 SCREW,MACHINE:6- - 32 X 1.750,PNH,STL,ZINC,T- - 15
1 CA ASSY,RF:RFS,0.141OD,50 OHM,SMA,JACK, X SMA,JACK
1 CHASSIS ASSY:SMALL MODULE,0.050 AL
18 SCREW,MACHINE:4- - 40 X 0.250,PNH,STL CD PLT,T10
4 STUD,LOCKING:0.850 X 0.188 HEX,SST
6 SPRING,TORSION:0.126OD X 0.094ID,DOOR,RIGHT,0.018DIA
4 COVER:SMALL MODULES,0.036 SST
6 SPRING,TORSION:0.126OD,0.094ID.DOOR,LEFT,0.018DIA
4 LEVER,EJECT:0.048 THK SSTL,SMALL MODULE
12 WASHER,SHLDR:0.375 OD X 0.115 ID X 0.093 THK
6 KNOB:EJECTOR LEVER,PC/ABS,SILVER GRAY
2 LEVER,EJECT:0.048 THK SSTL,LARGE MODULE
6 SPRING,TORSION:0.304 X 0.256 X 1.152
2 STUD,SHOULDERED:4- - 40 X 1.050L,SST
2 COVER:0.036 SST,LARGE MODULES
1 COVER, THERMAL, STOBE CIRCUITRY
1 SCREW; 6- - 32X 0.25,PNH,STL,ZI PLT,T- - 15,W/CAPTIVE FLAT WASHER
1 SPACER,POST; 0.312 L,6- - 32 STUD,BRS,ELECTROLESS NICKEL,0.25
HEX
