Tektronix DSA8200 Service Manual page 187

Figure 6- 12 Replaceable Parts List
Fig. & index Tektronix part
number number
6- - 12- - 1 380- - 1159- - 00
- - 2 211- - 0087- - 00
- - 3 333- - 4436- - 00
- - 4 335- - 0863- - 00
- - 5 211- - 0088- - 00
5
4
Figure 6- 12: 80E06 module
DSA8200 Digital Serial Analyzer and Modules Service Manual
Serial number Serial number
effective discont'd
1
2
3
Qty Name & description
1 HOUSING:SAMPLING HEAD,ALUMINUM,80E06, SAFETY CONTROLLED
2 SCREW,MACHINE:2- - 56 X 0.188,FLH,82 DEG SST,POZ
1 PANEL, FRONT:NSD HEADS,BLANK,386- - 5603- - 00,80E06
1 MARKER,IDENT:SAMPLING HEAD,2.760 X 0.810,0.010 POLY,W/ADHE-
SIVE,80E06,SAFETY CONTROLLED
4 SCREW,MACHINE:2- - 56 X 0.281,FLH,82 DEG,STL BK OXD,POZ
Replaceable Parts List
6- 25
