Removal and Installation Procedures
Left and Right Covers
4- - 16
1. Remove the left and right covers: See Figures 4- -5 and 4- -6, pages 4- -17
and 4- -18.
Trim (all)
Bottom cover
2. Orient the instrument: Set the instrument so its rear is on the work surface
and the front of the instrument facing the technician.
NOTE. All mounting screw holes are indicated by a star etched around the
mounting hole.
a. Remove the thirteen T-15 Torxdrive screws that secure the covers to the
top and both sides of the chassis.
b. Remove the nine T-15 Torxdrive screws that secure the covers to the
bottom of the chassis.
c. Pull the bottom-right cover down and slide to the right to remove from
the instrument. Pull the top-left cover upward and slide to the left to
remove from the instrument.
CAUTION. Take care not to bind or snag the covers on the instrument's internal
cabling as you remove or install.
3. Reinstallation: Do in reverse steps a through c to reinstall the cabinet.
DSA8200 Digital Serial Analyzer and Modules Service Manual
