Tektronix DSA8200 Service Manual page 171

Figure 6- 4 Replaceable Parts List
Fig. & index Tektronix part
number number
6- - 4- - 1 664- - 0214- - 00
664- - 0214- - 02
- - 2 156- - 9484- - 00
- - 3 664- - 0213- - 00
664- - 0213- - 01
- - 4 211- - 1050- - 00
- - 5 214- - 3903- - 00
- - 6 213- - 1061- - 00
- - 7 174- - 4241- - 01
- - 8 361- - 1762- - 00
- - 9 679- - 4761- - 00
- - 10 679- - 4760- - 00
- - 11 679- - 5660- - 00
- - 12 614- - 1042- - 00
- - 13 671- - 6297- - 00
- - 14 260- - 2724- - 00
- - 15 366- - 0770- - 00
- - 16 366- - 0771- - 00
- - 17 366- - 0772- - 00
- - 18 333- - 4527- - 00
- - 19 131- - 6417- - 00
- - 20 065- - 0767- - 00
- - 21 259- - 0155- - 01
- - 22 650- - 4623- - 00
- - 23 174- - 4189- - 00
- - 24 119- - 6995- - 00
- - 25 119- - 6806- - 00
- - 26 679- - 0217- - 00
- - 27 174- - 3618- - 00
DSA8200 Digital Serial Analyzer and Modules Service Manual
Serial number Serial number
effective discont'd
B010100 B029999
B030000
B010100 B029999
B030000
Qty Name & description
1 CIRCUIT BD ASSY;XGA, BRIDGE DSA8200,TESTED 6790214XX,SAFETY
CONTROLLED
1 CIRCUIT BD ASSY;XGA, BRIDGE DSA8200,TESTED 6790214XX,SAFETY
CONTROLLED
1 IC,MEMORY;CMOS,SDRAM;64MEG X 64,512MEG,SYNC,UNBUF-
FERED,3.3V;MT16LSDT6464AG- - 10E,DIMM168
1 CIRCUIT BD ASSY; BASE
1 CIRCUIT BD ASSY; BASE
8 SCREW,MACHINE:6- - 32 X 0.312 L,PNH,STL CAD,T15
2 SCREW, JACK; 4- - 40 X 0.312 LONG, 0.188 H HEX HEAD STAND OFF,
4- - 40 INT THD, X 0.312 THD EXT 4- - 40, STEEL, SN PLATED
2 JACKSCREW; 6- - 32 X 0.320 EXT THD,M3.5 X 0.6- - 6 INT THD X
0.215L,GPIB,BLACK OXIDE
1 CA,ASSY:RIBBON,BUS,IDC,32 AWG,17.00L,60POS
(PROCESSOR TO ACQ)
1 SPACER,SUPPORT:0.250 X 0.171 X 0.375,CKT BD,NYLON
1 CKT BD SUBASSY:POWER REAR
1 CKT BD SUBASSY:POWER FRONT
1 CIRCUIT BD ASSY;USB FRONT PANEL
1 FRONT PANEL MODULE; 8200 SERIES
(ITEMS 13 THROUGH 19)
1 CIRCUIT BD ASSY: USB FRONT PANEL CONTROL BD
1 SWITCH,KEYPAD:ELASTOMERIC,FRONT PANEL
3 KNOB,CAP:0.925 DIA
2 KNOB,CAP:SILVER GRAY,0.650 DIA X 0.520 H
3 KNOB,CAP:SIVER GRAY,0.425 DIA X 0.520 H
1 SUBPANEL, FRONT PANEL BRACKET W/LABEL, SAFETY CONTROLLED
3 CONTACT,ELEC; GROUNDING,0.600 L X 0.250 W X 0.220 D,ELECTRO-
LESS NICKEL PLATE
1 PARTS REPLACEMENT KIT, LCD MODULE AND INTERCONNECT
DISPLAY ADAPTOR BOARD;
(ITEMS 24 THROUGH 29)
1 FLEX CIRCUIT:POWER FLEX CIRCUIT SILVER INK
1 MODULE ASSY:TOUCH PANEL
1 CABLE ASSEMBLY:FLAT FLEX (DISPLAY ADAPTER)
1 DISPLAY MODULE; LCD
1 POWER SUPPLY; INVERTER,1200VAC NO- - LOAD & 600VAC @ 85KOHM
LOADED OUTPUT; 12VDC INPUT,PWM LUMINANCE CONTROLER,65KHZ
SWITCHING FREQ, SAFETY CONTROLLED
1 CKT BD SUBASSY:DISPLAY ADAPTER, W/HARDWARE
1 CA,ASSY SP:RIBBON,CPR,28 AWG,9.5 L,1X5,0.049CTR
Replaceable Parts List
6- 9
