Table 1-43
Expansion Rack
Type of Oracle Exadata Storage Expansion
Rack
Oracle Exadata Storage Expansion X3-2 Full
Rack
Oracle Exadata Storage Expansion X3-2 Half
Rack
Oracle Exadata Storage Expansion X3-2
Quarter Rack

1.9 Ensuring Site is Ready

Before Oracle Exadata Rack is delivered to the site, the following tasks must be
performed to ensure the site is ready:
(Cont.) IP Address Requirements for Oracle Exadata Storage
Ensuring Site is Ready
Network Requirements
Total of 60 IP addresses (42 for the
management network, and 18 for the private
InfiniBand network)
• 18 IP addresses for administration, one
per Exadata Storage Server
• 18 IP addresses for ILOM, one per
Exadata Storage Server
• 4 IP addresses for switches (3 for
InfiniBand, and 1 for Ethernet)
• 2 IP addresses for monitoring electric
current of the PDUs
• 18 IP addresses for the private InfiniBand
network
Total of 33 IP addresses (24 for the
management network, and 9 for the private
InfiniBand network)
• 9 IP addresses for administration, one per
Exadata Storage Server
• 9 IP addresses for ILOM, one per
Exadata Storage Server
• 4 IP addresses for switches (3 for
InfiniBand, and 1 for Ethernet)
• 2 IP addresses for monitoring electric
current of the PDUs
• 9 IP addresses for the private InfiniBand
network
Total of 17 IP addresses (13 for the
management network, and 4 for the InfiniBand
network)
• 4 IP addresses for administration, one per
Exadata Storage Server
• 4 IP addresses for ILOM, one per
Exadata Storage Server
• 3 IP addresses for switches (2 for
InfiniBand, and 1 for Ethernet)
• 2 IP addresses for monitoring electric
current of the PDUs
• 4 IP addresses for the private InfiniBand
network
