Oracle EXADATA X6-2 Installation And Configuration Manual page 215

I4 temperature 56,
maxtemperature 57
Temperature test returned OK
Starting FAN test:
Fan 0 not present
Fan 1 running at rpm 12946
Fan 2 running at rpm 12684
Fan 3 running at rpm 12558
Fan 4 not present
FAN test returned OK
Starting Connector test:
Connector test returned OK
Starting I4 test:
I4 OK
All I4s OK
I4 test returned OK
NM2 Environment test PASSED
Enable the InfiniBand Subnet Manager using the following command:
12.
# enablesm
Note:
If you get an error indicating the InfiniBand Subnet Manager is already
running, then restart it as follows:
# disablesm
# enablesm
Verify the IP address is correct using the following command:
13.
# ifconfig eth0
eth0 Link encap:Ethernet HWaddr 00:E0:4B:2A:07:2B
inet addr:172.16.10.32 Bcast:172.16.10.255
Mask:255.255.255.0
inet6 addr:fe80::2e0:3a00:fe2a:61e/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:11927 errors:0 dropped:0 overruns:0 frame:0
TX packets:89 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:720262 (703.3 KiB)TX bytes:11402 (11.1 KiB)
Verify the host name is correct using the following command:
14.
# hostname
dm01sw-ib2.example.com
Set the Subnet Manager Master as described in
15.
Master on Oracle Exadata Database Machine Full Rack and Oracle Exadata
Database Machine Half Rack
Exadata Database Machine Half Rack and Oracle Exadata Database Machine Full
Rack.
Log out from the InfiniBand switch using the following command:
16.
# exit
Configuring Sun Datacenter InfiniBand Switch 36 Switch
"Setting the Subnet Manager
(page 5-4)". This step is needed for Oracle
Chapter 5
5-3
