Table 1-37 (Cont.) IP Address Requirements for Oracle Exadata Database Machine X5-2 and
Later Systems
Type of Oracle Management
Exadata Database Network
Machine Requirements
• Oracle Exadata Minimum of 15 IP
Database addresses
Machine X5-2
•
and later Quarter
Rack
• Oracle Exadata
Database
Machine X5-2
•
and later Eighth
Rack
•
•
•
•
Network Connection and IP Address Requirements for Oracle Exadata Database Machine
Client Access
Network
Requirements
Minimum of 7 IP
addresses
2 IP addresses • 2 IP addresses
for for public
administration, access, one per
one per database server
database server
• 2 IP addresses
3 IP addresses for Oracle RAC
for VIP addresses,
administration, one per
one per Exadata database server
Storage Server
• 3 IP addresses
2 IP addresses for SCAN
for ILOM, one addresses for
per database Oracle RAC.
server
3 IP addresses
for ILOM, one
per Exadata
Storage Server
3 IP addresses
for switches: 2
for InfiniBand,
and 1 for
Ethernet
2 IP addresses
for monitoring
electric current
of the PDUs
Additional InfiniBand Private
Networks (NET2 Network
and NET3) Requirements
Requirements
Minimum of 2 IP For X5-2 and X6-2:
addresses for each 10 IP addresses:
additional network
• 4 IP addresses,
• 2 IP addresses two per
for the database database server
servers, one per
• 6 IP addresses,
database server
two per Exadata
If using a bonded Storage Server
network configuration
for the client access
network, then NET2
cannot be used as an
additional network.
