Table 2-3
X7-8
Network
Management (NET0)
The administration network
connection uses the 1 GbE
port even when using 10 GbE
ports for the other networks.
Client (BONDETH0)
Backup (BONDETH1)
2.4.1.3 Bonded Network Configuration for Oracle Exadata Database Machine
X4-8, X5-8, and X6-8
When using a bonded network configuration for database client access on Oracle
Exadata Database Machine X4-8, X5-8, and X6-8, the database servers are
configured as follows:
• Port NET0: Provides access to the operating system using the management
network through the ETH0 interface.
• P0 at 3 PCIe3: Provides access to the database using the client access network,
and is bonded with port P0 at 13 PCIe3, to create the BONDETH0 interface.
• P0 at 13 PCIe3: Provides access to the database using the client access network,
and is bonded with port P0 at 3 PCIe3 to create the BONDETH1 interface.
• Port NET MGT: Provides access to ILOM using the management network.
The following table shows the port connections for Oracle Exadata Database Machine
X4-8, X5-8, and X6-8 database servers when using channel bonding.
Table 2-4
X4-8, X5-8, and X6-8
Network
Management (NET0)
The administration network
connection uses the 1 GbE
port even when using 10 GbE
ports for the other networks.
Client (BONDETH0)
Channel Bonding Connections for Oracle Exadata Database Machine
Using 1 GbE Ports
• Port: 1 GbE NET0
• Connect to Cisco switch
• SMOD0 and SMOD1's
Net2
• Connect to client access
1 GbE switches
• SMOD0 and SMOD1's
Net3
• Connect to backup 1 GbE
switches
Channel Bonding Connections for Oracle Exadata Database Machine
Using 1 GbE Ports
• Port: 1 GbE NET0
• Connect to Cisco switch
• 1 GbE Ports: P0 at 3
PCIe3, and at 13 PCIe3
• Connect to client access
1 GbE switches
Chapter 2
Network Channel Bonding Support
Using 25 GbE Ports
• Port: 1 GbE NET0
• Connect to Cisco switch
• Port1 in PCIe 4 and 12
cards
• Connect to client access
25 GbE switches
• Port1 in PCIe 6 and 14
cards
• Connect to backup 25
GbE switches
Using 10 GbE Ports
• Port: 1 GbE NET0
• Connect to Cisco switch
• 10 GbE Ports: 2 PCIe3
PORTA, and 4 PCIe 3
PORTA
• Connect to client access
10 GbE switches
