The following are the PDUs that Exadata currently supports or has supported in the
past:
•
Table 1-24
(page 1-35) Low-voltage 15 kVA Single Phase PDUs for North
America, South America, Japan and Taiwan (2 PDUs per Rack)
•
Table 1-25
(page 1-36) Low-voltage 15 kVA Three Phase PDUs for North
America, South America, Japan and Taiwan (2 PDUs per Rack)
•
Table 1-26
(page 1-37) High-voltage 15 kVA Single Phase PDUs for Europe, the
Middle East and Africa (EMEA), and Asia Pacific (APAC), except for Japan and
Taiwan (2 PDUs per Rack)
•
Table 1-27
(page 1-38) High-voltage 15 kVA Three Phase for Europe, the Middle
East and Africa (EMEA), and Asia Pacific (APAC), except for Japan and Taiwan (2
PDUs per Rack)
•
Table 1-28
(page 1-39) Low-voltage 22 kVA Single Phase PDUs for North
America, South America, Japan and Taiwan (2 PDUs per Rack)
•
Table 1-29
(page 1-39) High-voltage 22 kVA Single Phase PDUs for Europe, the
Middle East and Africa (EMEA), and Asia Pacific (APAC), except for Japan and
Taiwan (2 PDUs per Rack)
•
Table 1-30
(page 1-40) Low-voltage 24 kVA Three Phase PDUs for North
America, South America, Japan and Taiwan (2 PDUs per Rack)
•
Table 1-31
(page 1-41) High-voltage 24 kVA Three Phase PDUs for Europe, the
Middle East and Africa (EMEA), and Asia Pacific (APAC), except for Japan and
Taiwan (2 PDUs per Rack)
•
Table 1-32
(page 1-42) Low-voltage 37 kVA Three Phase PDUs for North
America, South America, Japan and Taiwan (2 PDUs per Rack)
•
Table 1-33
(page 1-42) High-voltage 37 kVA Three Phase PDUs for Europe, the
Middle East and Africa (EMEA), and Asia Pacific (APAC), except for Japan and
Taiwan (2 PDUs per Rack)
Table 1-24
(page 1-35) lists the requirements for low-voltage single-phase PDUs for
North America, South America, Japan, and Taiwan. There are two PDUs per rack. The
following specifications are per PDU.
Table 1-24
Low-voltage 15 kVA Single Phase PDUs for North America, South
America, Japan and Taiwan (2 PDUs per Rack)
Option
Voltage
Frequency
Current
Power rating
Output current
Outlets
Outlet groups
Group protection (UL489 2-pole circuit
breaker)
Electrical Power Requirements
Requirement, per PDU
200 - 240 VAC
50/60 Hz
24 A maximum per input
15 kVA
72 A (3 x 24 A)
42 x C13; 6 x C19
6
20A
Chapter 1
1-35
