2.4.3 Additional Networks

• On Oracle Exadata Database Machine X7-2:
–
–
• On Oracle Exadata Database Machine two-socket systems (X2-2 to X6-2):
–
–
• On Oracle Exadata Database Machine X7-8:
–
–
• On Oracle Exadata Database Machine X5-8 and X6-8:
–
–
• On Oracle Exadata Database Machine X4-8 Full Rack:
–
–
• On Oracle Exadata Database Machine X3-8 Full Rack and X2-8 Full Rack:
–
–
Use of these additional network ports is optional, and the configuration varies
depending on your requirements and available network infrastructure. For example,
Note:
Oracle Exadata Database Machine X4-8 Full Rack, Oracle Exadata Database
Machine X3-8 Full Rack, and Oracle Exadata Database Machine X2-8 Full
Rack have BONDIB0, BONDIB1, and so on for the InfiniBand private network.
Non-bonded network configuration— There are four open ports (2x 1/10GbE
copper or 2x 10/25GbE optical ports and two additional 10/25GbE PCI ports)
on each database server.
Bonded network configuration— There are two open ports (10/25GbE PCI
ports) on each database server.
Non-bonded network configuration— There are four open ports (NET2, NET3,
and two additional 10 GbE ports) on each database server
Bonded network configuration— There are three open ports (NET3 and two
additional 10 GbE ports) on each database server
Non-bonded network configuration— There are 14 open ports (6 1/10GbE
ports and 8 10/25GbE PCI ports) on each database server
Bonded network configuration— There are 13 open ports (5 1/10 GbE ports
and 8 open 10/25 GbE PCI ports) on each database server
Non-bonded network configuration— There are 18 open ports (10 1GbE ports
and 8 10GbE ports) on each database server
Bonded network configuration— There are 15 open ports (7 1 GbE ports and 8
open 10 GbE ports) on each database server
Non-bonded network configuration— There are 16 open ports (8 1GbE ports
and 8 10GbE ports) on each database server
Bonded network configuration— There are 15 open ports (7 1 GbE ports and 8
open 10 GbE ports) on each database server
Non-bonded network configuration— There are 14 open ports (NEM0/NET2,
NEM0/NET3, NEM1/NET0, NEM1/NET1, NEM1/NET2, NEM1/NET3, and
eight additional 10 GbE ports) on each database server
Bonded network configuration— There are 13 open ports (NEM0/NET2,
NEM0/NET3, NEM1/NET0, NEM1/NET1, NEM1/NET2, and eight additional 10
GbE ports) on each database server
